IPv6 Multicast Listener Discovery snooping
2
Flags: R-Router Port, V1|V2: MLD Receiver, P_G|P_SG: PIM Join
1 (*, ff1e::6 ) 00:07:48 NumOIF: 1 profile: 8
Outgoing Interfaces:
e4/12 vlan 180 ( V1 ) 00:07:43/126s
1 (2001:1:1:1::180:101, ff1e::6) in e4/9 vlan 180 00:07:48 NumOIF:1 profile: 8
Outgoing Interfaces:
e4/12 vlan 180 ( V1 ) 00:07:43/0s
FID: 0x8015 MVID: None
2 (*, ff1e::4 ) 00:07:48 NumOIF: 1 profile: 8
Outgoing Interfaces:
e4/12 vlan 180 ( V1 ) 00:07:43/126s
Syntax: show ipv6 multicast [vlan vlan-id]
The vlan vlan-id parameter displays IPv6 multicast PIM information for a specified port-based
VLAN. The vlan-id variable is entered in decimal format.
Table 51 describes the output parameters of the show ipv6 multicast vlan command.
TABLE 51 Output parameters of the show ipv6 multicast vlan command
Field Description
VLAN Shows the ID of the configured VLAN.
State Shows whether the VLAN interface is enabled or disabled.
Mode Shows whether the VLAN interface is in active mode or passive mode.
Active Querier Shows the active IGMP querier for the VLAN.
Time Query Shows the time countdown to generate the next query message.
(*, G)Count Shows the count of (*,G) entries.
(S, G)Count Shows the count of (S,G) entries.
Flags Shows the interface flag for the entry.
V1|V2 Shows the version of the IGMP message received.
P_G Indicates that a PIM (*,G) join was received on that interface.
P_SG Indicates that a PIM (S,G) join was received on that interface.
NumOIF Show the count of the outgoing interfaces.
profile Shows the profile ID associated with the stream.
Outgoing Interfaces Shows the outgoing interfaces.
FID Shows the FID resource allocated for a particular entry.
MVID Shows the MVID resource allocated for a particular entry.
