120

Multi-Service IronWare Multicast Configuration Guide

53-1003032-02

IGMP V3

1

The acl-id/acl-name parameter specifies the ACL id or name used to configure multiple SSM group
ranges.

To disable the SSM mapping range ACL, use the no form of this command.

NOTE

The ssm-enable range acl-id or acl-name command also supports IPv6 traffic. The ssm-enable
range acl-id or acl-name command must be configured under the IPv6 router pim configuration to
support IPv6.

Displaying information for PIM SSM range ACL

To display information for PIM SSM range ACL configuration enter the following command at any
CLI level:

NOTE

The show ipv6 pim sparse command also displays PIM SSM range ACL configuration.

IGMPv2 SSM mapping

The PIM-SSM feature requires all IGMP hosts to send IGMPv3 reports. Where you have an IGMPv2
host, this can create a compatibility problem. In particular, the reports from an IGMPv2 host
contain a Group Multicast Address but do not contain source addresses. The IGMPv3 reports
contain both the Group Multicast Address and one or more source addresses. This feature converts
IGMPv2 reports into IGMPv3 reports through use of the ip igmp ssm-map commands and a
properly configured ACL.

The ACL used with this feature filters for the Group Multicast Address. The ACL is then associated
with one or more source addresses using the ip igmp ssm-map static command. When the ip igmp
ssm-map enable command is configured, IGMPv3 reports are sent for IGMPv2 hosts.

The following sections describe how to configure the ACL and the ip igmp ssm-map commands to
use the IGMPv2 SSM mapping feature:

Configuring an ACL for IGMPv2 SSM mapping

Configuring the IGMPv2 SSM Mapping Commands

Brocade#show ip pim sparse

Global PIM Sparse Mode Settings

Maximum Mcache : 0 Current Count : 0

Hello interval : 30 Neighbor timeout : 105

Join/Prune interval : 60 Inactivity interval : 180

Register Suppress Time : 60 Register Probe Time : 10

SPT Threshold : 1 Hardware Drop Enabled : Yes

Bootstrap Msg interval : 60 Candidate-RP Msg interval : 60

Register Stop Delay : 60 Register Suppress interval : 60

SSM Enabled : Yes

SSM Group Range : 224.1.1.1/24

SSM Group Range ACL : xyz

Route Precedence : mc-non-default mc-default uc-non-default uc-default
