18-16
IM MX190-01E
Mnemonic Description Setting range
DAQMX100_RANGE_RTD_2MACU10WEEDH Cu10:WEED –200.0 to 300.0°C
:High resolution –328.0 to 572.0°F
DAQMX100_RANGE_RTD_2MACU10BAILEYH Cu10:BAILEY –200.0 to 300.0°C
:High resolution –328.0 to 572.0°F
DAQMX100_RANGE_RTD_2MAPTN Pt100 –200.0 to 250.0°C
:high noise resistance –328.0 to 482.0°F
DAQMX100_RANGE_RTD_2MAJPTN Jpt100 –200.0 to 250.0°C
:high noise resistance –328.0 to 482.0°F
DAQMX100_RANGE_RTD_2MACU100G Cu100G –200.0 to 200.0°C
–328.0 to 392.0°F
DAQMX100_RANGE_RTD_2MACU50G Cu50G –200.0 to 200.0°C
–328.0 to 392.0°F
DAQMX100_RANGE_RTD_2MACU10G Cu10G –200.0 to 200.0°C
–328.0 to 392.0°F
RTD (other ) Ranges
Mnemonic Description Setting range
DAQMX100_RANGE_RTD_025MAPT500 0.25 mA Pt500 –200.0 to 600.0°C
–328.0 to 1112.0°F
DAQMX100_RANGE_RTD_025MAPT1K 0.25 mA Pt1000 –200.0 to 600.0°C
–328.0 to 1112.0°F
Resistance Ranges
Mnemonic Description Setting range
DAQMX100_RANGE_RES_20 20 Ω 0 to 20.000
DAQMX100_RANGE_RES_200 200 Ω 0 to 200.00
DAQMX100_RANGE_RES_2K 2 kΩ (0.25mA) 0 to 2000.0
18.2 MX100 Constants
