6-13
IM MX190-01E
MX100 Constants and Types
6
RTD (2 mA) Range Types
Mnemonic Description Setting range
DAQMX_RANGE_RTD_2MAPT Pt100 –200.0 to 250.0°C
–328.0 to 482.0°F
DAQMX_RANGE_RTD_2MAJPT JPt100 –200.0 to 250.0°C
–328.0 to 482.0°F
DAQMX_RANGE_RTD_2MAPTH Pt100: high resolution –140.00 to 150.00°C
–220.0 to 302.0°F
DAQMX_RANGE_RTD_2MAJPTH JPt100: high resolution –140.00 to 150.00°C
–220.0 to 302.0°F
DAQMX_RANGE_RTD_2MAPT50 Pt50 –200.0 to 550.0°C
–328.0 to 1022.0°F
DAQMX_RANGE_RTD_2MACU10GE CU10:GE –200.0 to 300.0°C
–328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU10LN Cu10:L&N –200.0 to 300.0°C
–328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU10WEED Cu10:WEED –200.0 to 300.0°C
–328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU10BAILEY Cu10:BAILEY –200.0 to 300.0°C
–328.0 to 572.0°F
DAQMX_RANGE_RTD_2MAJ263B J263*B 0.0-300.0K
0.0 to 300.0K
DAQMX_RANGE_RTD_2MACU10A392 Cu10 at 20°C –200.0 to 300.0°C
a=0.00392 –328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU10A393 Cu10 at 20°C –200.0 to 300.0°C
a=0.00393 –328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU25 Cu25 at 0°C –200.0 to 300.0°C
a=0.00425 –328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU53 Cu53 at 0°C –50.0 to 150.0°C
a=0.00426035 –58.0 to 302.0°F
DAQMX_RANGE_RTD_2MACU100 Cu100 at 0°C –50.0 to 150.0°C
a=0.00425 –58.0 to 302.0°F
DAQMX_RANGE_RTD_2MAPT25 Pt25 –200.0 to 550.0°C
–328.0 to 1022.0°F
DAQMX_RANGE_RTD_2MACU10GEH CU10:GE: high resolution –200.0 to 300.0°C
–328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU10LNH Cu10:L&N: high resolution –200.0 to 300.0°C
–328.0 to 572.0°F
DAQMX_RANGE_RTD_2MACU10WEEDH Cu10:WEED: high resolution
–200.0 to 300.0°C
–328.0 to 572.0°F
6.2 MX100 Constants
