6-28
IM MX190-01E
MXChConfigAI
MXChConfigAI structure
Visual C/C++ Type Name Description Visual Basic Type
int aFilter Filter time constant Long
int aRJCType RJC type Long
int aRJCVolt RJC Voltage Long
int aBurnout Burnout Long
Retrieval/Change
Name Description Basic Settings
AI PI CI
aFilter Filter time RC RC RC
constant
aRJCType RJC type RC
aRJCVolt RJC Voltage RC
aBurnout Burnout RC
Setup data structure for AI channels.
MXChConfigDO
MXChConfigDO structure
Visual C/C++ Name Description Visual Basic Type
Type
int aDeenergize De-energize (presence Long
or absence)
int aHold Hold (presence or absence) Long
unsigned char [ ] [ ] aRefAlarm Reference alarms (1 To 4, 1
(presence or
absence)
To 60) As
Byte
* The order of two-dimensional arrays are opposite between Visual C/Visual C++ and VB.
Retrieval/Change
Name Description Basic Settings
DO
aDeenergize De-energize (presence or absence) RC
aHold Hold (presence or absence) RC
aRefAlarm Reference alarms (presence or absence) RC
Setup data structure for DO channels.
6.5 MX100 Types
