6-15
IM MX190-01E
MX100 Constants and Types
6
Digital Input (DI) Detailed Range Types
Mnemonic Description
DAQMX_RANGE_DI_LEVEL_AI DI/Level of the universal input module
DAQMX_RANGE_DI_CONTACT_AI4 DI/Contact input of the 4-CH, Universal
Input Module
DAQMX_RANGE_DI_CONTACT_AI10 DI/Contact input of the 10-CH, Universal
Input Module
DAQMX_RANGE_DI_CONTACT_AI30 DI/Contact input of the 30-CH, Universal
Input Module
DAQMX_RANGE_DI_LEVEL_DI DI/Level of the digital input module
DAQMX_RANGE_DI_CONTACT_DI DI/Contact input of the digital input module
DAQMX_RANGE_DI_LEVEL_DI5V* DI 5V
DI/contact input of the digital input module (5 V)
DAQMX_RANGE_DI_LEVEL_DI24V DI 24V
DI/contact input of the digital input module
(24 V)
* Separate name for DAQMX_RANGE_DI_LEVEL_DI. Defined to differentiate from 24 V.
Strain Ranges
Mnemonic Description Setting range
DAQMX_RANGE_STRAIN_2K 2000 µSTR –2000.0 to 2000.0
±563200000
DAQMX_RANGE_STRAIN_20K 20000 µSTR –20000 to 20000
±56320000
DAQMX_RANGE_STRAIN_200K 200000 µSTR –200000 to 200000
±5632000
AO Ranges
Mnemonic Description Setting range
DAQMX_RANGE_AO_10V V output –10.000 to 10.000 V
DAQMX_RANGE_AO_20MA mA output 0.000 to 20.000 mA
PWM Ranges
Mnemonic Description Setting range
DAQMX_RANGE_PWM_1MS PWM output resolution 1 ms 0 to 100.000 %
DAQMX_RANGE_PWM_10MS PWM output resolution 10 ms 0 to 100.000 %
Communication Range
Mnemonic Description Setting range
DAQMX_RANGE_COM_CAN CAN Bus –30000 to 30000
Pulse Ranges
Mnemonic Description Setting range
DAQMX_RANGE_PI_LEVEL Pulse/Level input 0 to 30000
DAQMX_RANGE_PI_CONTACT Pulse/Contact input 0 to 30000
6.2 MX100 Constants
