7-33
IM MX190-01E
DARWIN - Visual C++ -
7
CDAQDARWIN::setRTD
Syntax
int setRTD(int iRangeRTD, int chType, int startChNo, int
endChNo = 0, int spanMin = 0, int spanMax = 0, int scaleMin =
0, int scaleMax = 0, int scalePoint = 0);
Parameters
iRangeRTD Specify the range type of the RTD input.
chType Specify the channel type of the measurement channel.
startChNo Specify the start channel number.
endChNo Specify the end channel number.
spanMin Specify the left value of the span.
spanMax Specify the right value of the span.
scaleMin Specify the left value of the scale.
scaleMax Specify the right value of the scale.
scalePoint Specify the decimal point position for scaling.
Description
Sets the specified RTD range to the measurement channels in the specified channel
range (specified by channel type, start channel number, and end channel number).
This function executes the SR command of the DARWIN communication function.
It creates and sends the command and receives the response.
If the left and right values are the same, the span or scale designation is considered
omitted.
Return value
Returns an error number.
Reference
runCommand
CDAQDARWINChInfo::toChRange
7.4 Details of the DARWIN Class
