2-5
IM MX190-01E
MX100 -Visual C++
2
Setup Functions
Collective Setup
Function FIFO Class and Member Function
Configure the setup data collectively Stop CDAQMX::setConfig
Set the DO (Digital Output) data collectively Continue CDAQMX::setDOData
Set the basic settings collectively Stop CDAQMX::setMXConfig
Set the 7-segment LED display Continue CDAQMX::setSegment
Transmit AO/PWM data Continue CDAQMX::setAOPWMData
Send transmission output data Continue CDAQMX::setTransmit
Set initial balance data Stop CDAQMX::setBalance
Set output channel data Stop CDAQMX::setOutput
Initial balance data Execute Stop CDAQMX::runBalance
Reset Stop CDAQMX::resetBalance
For a description of the FIFO column in the table, see the explanation given in
“Other Controls” on the previous page. With Visual Basic, setting data cannot be
handled collectively.
2.2 Correspondence between the Functions and Class/Member Functions - MX100
