20-3
IM MX190-01E
20
DARWIN for Extended API - Visual C -
Data Retrieval Functions
Function Command Function
Measured data Meas ch TS, FM measInstChDA100
(instantaneous value) Comp ch TS, FM mathInstChDA100
Channel Meas ch TS, LF measInfoChDA100
information data Comp ch TS, LF mathInfoChDA100
System configuration data TS, CF updateSystemConfigDA100
Report status TS,RF updateReportStatusDA100
Setup data
Declar. Op Sngl spec TS, LF talkOperationChDataDA100
mode Specify range TS, LF talkOperationDataDA100
Setup Sngl spec TS, LF talkSetupChDataDA100
mode Specify range TS, LF talkSetupDataDA100
Cal Sngl spec TS, LF talkCalibrationChDataDA100
mode Specify range TS, LF talkCalibrationDataDA100
Get data in units of lines - getSetDataByLineDA100
Setup data is not stored, so it is retrieved in the same order as mentioned in
sections 7.2 and 7.3. In this case, status is not updated.
Channel information data and system configuration data are stored internally, but
the user can explicitly perform acquisition.
The report status is stored internally, but is not updated unless the user explicitly
acquires it.
20.1 Functions and Their Functionalities - DARWIN/Visual C -
