13-4
IM MX190-01E
Module Settings
Function FIFO Function
Interval type Stop setIntervalMX100
A/D integral time type Stop setIntegralMX100
Unit Settings
Function FIFO Function
Unit number Stop setUnitNoMX100
Temperature unit type Stop setUnitTempMX100
CF write mode Stop setCFWriteModeMX100
Output Channel Data
Function FIFO Function
Output type Stop setOutputTypeMX100
Selected value Stop setChoiceMX100
setDoubleChoiceMX100
Pulse interval integer multiple Stop setPulseTimeMX100
The setup functions send the settings then update the status.
These settings are for individual channels. If the settings could not be entered, an
error is usually returned.
Specification is possible with data values or measured values (Double).
13.1 Functions and Their Functionalities - MX100/Visual C -
