25-1
IM MX190-01E
25
DARWIN for Extended API Constants and Types
Chapter 25 DARWIN for Extended API Constants and Types
25.1 Overview of the DARWIN Constants
This Extended API provides the following types of constants.
In Visual C/Visual C++, the constants from chapter 11.1 are inherited. Also,
constants, retrieval code types, range types, and skip range constants have been
added for the Extended API. See section 25.2.
The constants for Visual Basic and Visual Basic.NET/C# are listed in section 25.2.
Type Description Page
Constants Channel numbers in the unit, etc. 25-2, 25-5
Retrieve code types Binary code, ASCII code 25-2, 25-5
Comm constants Communication port number of DARWIN 11-2, 25-5
Numbers of items Number of subunits, etc. 11-2, 25-5
Maximum values Maximum length of the channel name 11-2, 25-6
string, etc.
Boolean values Valid (ON) setting or Invalid (OFF) setting 11-2, 25-6
Flag statuses Detects the last data set when data is 11-3, 25-6
retrieved
Data status values Status of the measured data 11-3, 25-6
Alarm types Upper-limit alarm, etc. 11-3, 25-7
Channel/relay types Channel or relay types 11-4, 25-7
Operation modes Operation, setup, and A/D calibration mode 11-4, 25-7
Talker function types Talker supporting output data 11-4, 25-8
Status byte values Various statuses 11-5, 25-8
Establish setup modes Destroy, establish 11-5, 25-8
Unit numbers Expandable model, standalone model 11-5, 25-8
Computations Calculation start, stop, clear, etc. 11-5, 25-9
Report execution types Report start/stop 11-5, 25-9
Report types Hourly, daily, monthly, status 11-6, 25-9
Report statuses Invalidate all report types, latest info, valid 11-6, 25-9
Range types
DC voltage range types 20 mV, etc. 11-6, 25-3, 25-10
TC range types Type R, etc. 11-6, 25-3, 25-10
RTD range types Pt100: 1 mA, etc. 11-7, 25-3, 25-11
Contact input rng types Voltage level or contact input 11-7,25-4, 25-11
Strain input ranges 2 k, 20 k, 200 k 11-7, 25-4, 25-11
Pulse ranges GATE, RATE 11-7,25-4, 25-11
Power monitor ranges 25 V 0.5 A, 25 V 5 A, 250 V 0.5 A, 250 V 5 A 11-8,25-4, 25-12
Power connection methods Single-phase two-wire, etc. 11-8, 25-12
DC current ranges 20 mA 11-8, 25-4, 25-12
SKIP ranges Skip 25-4, 25-12
Power connection methods Single-phase two-wire, etc. 11-8, 25-12
Power meas parameters Effective current, etc. 11-9, 25-13
