2-146
IM MX190-01E
CDAQMXConfig::setPULSE
Syntax
void setPULSE(int chNo, int iRangePULSE, int spanMin = 0, int
spanMax = 0);
Parameters
chNo Specify the channel number.
iRangePULSE Specify the pulse range from the range type.
spanMin Specify the span minimum.
spanMax Specify the span maximum.
Description
Sets the channel of the specified channel number to the specified range.
If the maximum and minimum values are the same, the span is considered omitted.
If the channel does not exist or the channel is not on the corresponding module, the
setting is void.
If the constant for “Specify all channel numbers” is specified for the channel
numbers, all channels are processed.
Reference
getClassMXChConfig getClassMXSysInfo CDAQMXChConfig::setPULSE
CDAQMXChConfig::setSpan CDAQMXSysInfo::getModuleType
ßCDAQMXSysInfo::getTempUnit
CDAQMXConfig::setPWM
Syntax
void setPWM(int chNo,int iRangePWM,int spanMin = 0,int spanMax
= 0);
Parameters
chNo Specify the channel number.
iRangePWM Specify the PWM range type.
spanMin Specify the span minimum.
spanMax Specify the span maximum.
Description
Sets the channel of the specified channel number to the specified range.
If the maximum and minimum values are the same, the span is considered omitted.
If the channel does not exist or the channel is not on the corresponding module, the
setting is void.
If the constant for “Specify all channel numbers” is specified for the channel
numbers, all channels are processed.
The output type of the output channel data is reset to match the specified range.
Reference
getClassMXChConfig getClassMXOutputData
getClassMXSysInfo CDAQMXChConfig::setSpan
CDAQMXChConfig::setPWM CDAQMXOutputData::setOutputType
CDAQMXSysInfo::getModuleType CDAQMXSysInfo::getTempUnit
2.5 Details of the MX100 Class
