App-17
IM MX190-01E
Appendix
App
Status Byte
A value indicating the status of the instrument. A value synthesized through logical
OR computations of the status byte.
System Configuration Data
Unit and module information.
See the DarwinSystemInfo structure.
Unit Number
A number identifying the unit in the system configuration.
See Channel/Relay types.
It is either the main unit or subunit number.
On the standalone model, the only valid unit number is 0.
Subunit Number
A number used to identify the subunit connected on the expandable model.
It is an integer value between 0 and 5.
On the standalone model, this number is the same as the unit number, and the only
valid subunit number is 0.
Slot Number
Represents the position where the module is connected for each unit.
It is an integer value between 0 and 5.
Terminal Number
A number used to identify the position of the channel/relay in the module connected
to the slot.
It is an integer value between 1 and 10.
Differs depending on the module type.
Talker
A function that performs data output. The types indicated by the talker function type
are supported.
Since the data of multiple channels or lines are output, data retrieval commands are
executed by channel or by line after the start command is executed.
Terminator
String indicating the end of the command.
Appendix 2 DARWIN Terminology
