Yokogawa PC-Based MX100 User Manual
Page 574
12-10
IM MX190-01E
Channel Setup Data
Data Name
Class and Member Function
Channel status (valid/invalid)
CDAQMXChConfig:: isValid
Decimal Point Position
CDAQMXChConfig:: getPoint
Channel kind
CDAQMXChConfig:: getKind
Range type
CDAQMXChConfig:: getRange
Scale type
CDAQMXChConfig:: getScale
Unit name
CDAQMXChConfig:: getUnit
Tag
CDAQMXChConfig:: getTag
Comment
CDAQMXChConfig:: getComment
AI/DI/ Span
Min value
Data value
CDAQMXChConfig:: getSpanMin
Meas values CDAQMXItemConfig:: getDoubleSpanMin
Max value
Data value
CDAQMXChConfig:: getSpanMax
Meas value
CDAQMXItemConfig:: getDoubleSpanMax
AI/DIAO/PWM
Scale
Min value
Data value
CDAQMXChConfig:: getScaleMin
Meas value
CDAQMXItemConfig:: getDoubleScaleMin
Max value
Data value
CDAQMXChConfig:: getScaleMax
Meas values CDAQMXItemConfig:: getDoubleScaleMax
Alarm type
CDAQMXChConfig:: getAlarmType
Alarm value (ON)
Data Value
CDAQMXChConfig:: getAlarmValueON
Meas values CDAQMXItemConfig:: getDoubleAlarmON
Alarm value (OFF)
Data Value
CDAQMXChConfig:: getAlarmValueOFF
Meas value
CDAQMXItemConfig:: getDoubleAlarmOFF
Hysteresis
Data Value
CDAQMXItemConfig:: getHisterisys
Meas value
CDAQMXItemConfig:: getDoubleHisterisys
AI
Filter
CDAQMXChConfig:: getFilter
RJC type
CDAQMXChConfig:: getRJCType
RJC voltage
CDAQMXChConfig:: getRJCVolt
Burnout
CDAQMXChConfig:: getBurnout
DO
De-energize
CDAQMXChConfig:: isDeenergize
Hold
CDAQMXChConfig:: isHold
Reference alarm
CDAQMXChConfig:: isRefAlarm
Channels under going difference between channels computation/RRJC/AO/PWM
Ref. channel CDAQMXChConfig:: getRefChNo
number
Initial bal data
Boolean value
CDAQMXBalanceData:: getBalanceValid
Initial balance value
CDAQMXBalanceData:: getBalanceValue
Output
Output type
CDAQMXOutputData:: getOutputType
channel data
Selection when idle
CDAQMXOutputData:: getIdleChoice
Selection during error
CDAQMXOutputData:: getErrorChoice
Value if the selected value is the “specified value.”
Data value
CDAQMXOutputData:: getPresetValue
Meas value
CDAQMXItemConfig:: getDoublePresetValue
Pls intrvl integer mult.
CDAQMXOutputData:: getPulseTime
PI
Chattering filter
CDAQMXChConfig:: isChatFilter
12.1 MX100 Class
