MX100 -Visual C++
2
CDAQMXConfig Class
This class stores the setup data of the MX100.
It is a wrapper class of the MXConfigData structure.
This class can be used as an interface for storing setup data when retrieving setup
data.
Public Members
Construct/Destruct
CDAQMXConfig Constructs an object.
~CDAQMXConfig Destructs an object.
Structure Manipulation
getMXConfigData Gets the data in a structure.
setMXConfigData Sets the data in a structure.
initMXConfigData Initializes the data in a structure.
Member Data Manipulation
initialize Initializes the data member.
getClassMXSysInfo Gets the system configuration data.
getClassMXStatus Gets the status.
getClassMXNetInfo Gets the network information data.
getClassMXChConfigData Gets the channel setup data.
getClassMXBalanceData Gets initial balance data.
getClassMXOutputData Gets the basic output channel data.
getClassMXChConfig Gets individual channel setup data.
reconstruct Reconstructs the system.
setTempUnit Sets the temperature unit type.
setDOType Sets the DO channel type.
setInterval Set the interval type.
setAOType Sets the AO channel type.
setPWMType Sets the PWM channel type.
Range Settings
setSKIP Sets SKIP (not used).
setVOLT Sets DC voltage input.
setTC Sets thermocouple input.
setRTD Sets RTD input.
setDI Sets digital input (DI).
setDELTA Sets difference computation between channels.
setRRJC Sets remote RJC.
setScalling Sets the scale.
2.5 Details of the MX100 Class
