Character Strings
Notations for characters strings in item contents are as follows.
• The valid/invalid value (Boolean) is notated as OFF or ON.
• The string itself is shown as-is.
• Values are written as decimals. However, hexadecimal is used to notate
significant bits when present.
• The alarm levels of reference channels are expressed as valid channel numbers
(01, 02, etc.).
• The choices are given by the name of the string. They are expressed as
character strings, abbreviated as much as possible while retaining their
usefulness for identifying mnemonics for constants.
Ranges
Mnemonic Description
DAQMX_ITEM_ALL_START First number of all items
DAQMX_ITEM_ALL_END_R1 End number of all items for style version 1
DAQMX_ITEM_ALL_END_R2 End number of all items for style version 2
DAQMX_ITEM_ALL_END_R3 End number of all items for style version 3
DAQMX_ITEM_ALL_END End number of all items for most recent style
version
Masks
Mnemonic Description
DAQMX_MASK_BYMODULE Module number mask
DAQMX_MASK_BYCHANNEL Channel number mask
DAQMX_MASK_BYFIFO FIFO number mask
DAQMX_MASK_BYALARM Alarm level number mask
Note that the alarm level number mask shows the position of the 7th bit from the
end.
Index
Mnemonic Description
DAQMX_MAX_INDEX_FIFO FIFO maximum index value
DAQMX_MAX_INDEX_MODULE Module maximum index value
DAQMX_MAX_INDEX_CHANNEL Channel maximum index value
