16-8
IM MX190-01E
Channel Setup Data
Data Name
Function
Channel status (valid/invalid)
DAQMX100. channelValidMX100
Decimal point position
DAQMX100. channelPointMX100
Channel kind
DAQMX100. channelKindMX100
Range type
DAQMX100. channelRangeMX100
Scale type
DAQMX100. channelScaleTypeMX100
Unit name
DAQMX100. toChannelUnitMX100
Tag
DAQMX100. toChannelTagMX100
Comment
DAQMX100. toChannelCommentMX100
AI/DI/AO/
Span Min value
Data val
DAQMX100. channelSpanMinMX100
PWM
Measval
DAQMX100. channelDoubleSpanMinMX100
Max value
Data val
DAQMX100. channelSpanMaxMX100
Meas val
DAQMX100. channelDoubleSpanMaxMX100
AI/DI
Scale Min value
Data val
DAQMX100. channelScaleMinMX100
Meas val
DAQMX100. channelDoubleScaleMinMX100
Max val
Data val
DAQMX100. channelScaleMaxMX100
Meas val
DAQMX100. channelDoubleScaleMaxMX100
Alarm type
DAQMX100. alarmTypeMX100
Alarm value (ON) Data val
DAQMX100. alarmValueONMX100
Meas val
DAQMX100. alarmDoubleValueONMX100
Alarm value (OFF) Data val
DAQMX100. alarmValueOFFMX100
Meas val
DAQMX100. alarmDoubleValueOFFMX100
Hysteresis
Data val
DAQMX100. alarmHisterisysMX100
Meas val
DAQMX100. alarmDoubleHisterisysMX100
AI
Filter
DAQMX100. channelFilterMX100
RJC type
DAQMX100. channelRJCTypeMX100
RJC voltage
DAQMX100. channelRJCVoltMX100
Burnout
DAQMX100. channelBurnoutMX100
DO
De-energize
DAQMX100. channelDeenergizeMX100
Hold
DAQMX100. channelHoldMX100
Reference alarm
DAQMX100. channelRefAlarmMX100
Channels undergoing difference between
channels computation/Remote RJC/AO/PWM
Reference channel number
DAQMX100. channelRefChNoMX100
Initial balance data
Valid/Invalid value
DAQMX100. channelBalanceValidMX100
Initial balance value
DAQMX100. channelBalanceValueMX100
Output channel data Output type
DAQMX100. channelOutputTypeMX100
Selection when idle
DAQMX100. channelIdleChoiceMX100
Selection during err
DAQMX100. channelErrorChoiceMX100
Value if the selected value is the “specified value.”
Data val
DAQMX100. channelPresetValueMX100
Meas val
DAQMX100. channelDoublePresetValueMX100
Pulse interval
DAQMX100. channelPulseTimeMX100
integer multiple
PI
Chattering filter
DAQMX100. channelChatFilterMX100
16.1 Functions and Their Functionalities - MX100/C# -
