E-46
IM 01R01A01-01E 9th Edition : May 31, 2013-00
 Properties
Clicking a Properties button opens the following screen. This screen enables you to confirm
detailed information on the parameters in the Device Values area/Work area.
E030307E.ai
Device : actual device
File : file or database
Figure E-3-23 Parameter Manager Window – Properties
 Export Parameters
Selecting Save/Export Device Values or clicking the corresponding button opens the following
screen. This screen enables the parameter values of the device (Device Values area) or the
parameter values in the Work area to be exported to a file or saved.
The following dialog box appears if you select Save/Export.
The character string you enter in the following dialog box appears in History.
E030308E.ai
Click this button to export
the parameters to a file.
The default format for the comment is
“Device Tag, Device ID”
Figure E-3-24 Parameter Manager Window – Export Parameters
