J-13
IM 01R01A01-01E 9th Edition : May 31, 2013-00
 Device File Installer of Converted HART DTM
Device File Installer is applied for Converted HART DTM of other manufacturers.
 Window
J020108E.ai
Displays a list of DTMs that can be installed Select the
checkbox of any DTM you want to install and click the
Install button to start installation.
You can also use the Check and Uncheck buttons.
Use the Shift and Control keys to select multiple
checkboxes.
Selecting or unselecting a checkbox causes
the required disk space to change. If the
required disk space exceeds the free disk
space on the PC, the Install button becomes
unavailable.
Converted DTM files for DD Rev.N: Indicates the
DTM converted from DD revision “N”
Click a title to sort the items accordingly
All checkboxes are not selected by default. Device icons and the Device Viewer definition files are always
installed regardless of the checkboxes selected. However, if a file of the same name already exists, the file is not
installed if the corresponding file on the PC has a more recent date.
For DTM supporting multiple device revisions, the supported
device revision numbers that are displayed are separated by a
comma (eg.: 1, 2, 3)
For DTM supporting all device revisions, “ALL” is displayed.
Figure J-2-8
