App.-43
IM 01R01A01-01E 9th Edition : May 31, 2013-00
2. Click [Download] button.
A dialog box showing the communication progress will be displayed indicating the download
is running.
App.E10E.ai
ACTIVATE processing is completed
during Communication executing.
Figure App.-E-10 Commuication Executing Dialog Box
IMPORTANT
When a communication error occurs, retry software download again. In that case, if procedure
of software download fails due to internal status of FOUNDATION fieldbus device, retry software
download once again.
3. Clicking [Stop] button on the Communication Executing dialog box can stop the
downloading. After clicking this button, a confirmation dialog box displays, clicking [OK] will
stop the downloading. However, if the following message occurs during the downloading
communication, the downloading process cannot be stopped.
• The software downloading to the device starts.
Software Name:
App.E11E.ai
Figure App.-E-11 Stop Confirmation Dialog Box
