E-20
IM 01R01A01-01E 9th Edition : May 31, 2013-00
 Startup
E030201E.ai
Yes
Selection window for
Offline Parameter appears.
No
Default data is loaded and Online Parameter window appears.
Select options to load stored data or default data for offline parameters.
- “Load From Database”: Loads data from the database. After data is loaded,
the parameters refresh automatically. (Only for FieldMate Advance)
- “Load From File”: Loads data from a specific file. After data from the
specified file is loaded, the parameters refresh automatically.
- “Load Default Data”: Loads default data. After default data is loaded, the
parameters refresh automatically.
In Option setting menu of DTM Works, is the
check box of [Show “Load option for DTM data”
dialog at startup] checked?
Figure E-3-3 DTM Startup
 Built-in Connection (BIC Mode)
This connection mode called Built-in Connection employs a built-in communication method
of FieldMate, which is available for different communication protocols such as HART,
FOUNDATION fieldbus, PROFIBUS, BRAIN, and ISA100.
For HART and BRAIN communication, you can use an optional USB FieldMate modem by
directly connecting it to the field device.
Also, for FOUNDATION fieldbus and PROFIBUS communication, you need to separately
purchase a NI-FBUS from National Instruments or FFusb from Softing (for FOUNDATION
