I-3 HART adaptor
I-3-1 Configuration example
The Honeywell OWA 100 OneWireless Adaptor (“HART adaptor”) connects with HART devices
and conducts ISA100 wireless communication via the field wireless gateway.
I030101E.ai
HART
adaptor
HART device
ISA100
FieldMate
Field wireless
gateway
Figure I-3-1
Image of HART Adaptors
