E-1-2 Main Window
NOTE
Login your PC with “Administrator” privilege.
Startup Sequence
E010201E.ai
Start FieldMate
What is selected for automatic scan
immediately after startup?
Selected protocol in Segment Viewer,
HART, FOUNDATION fieldbus,
PROFIBUS, BRAIN or ISA100 is
displayed.
History is displayed.
The Login dialog box appears.
It includes the user ID (*) and password, and the
setting for whether to perform an automatic scan
immediately after startup (*).
HART, FOUNDATION fieldbus, PROFIBUS, BRAIN or ISA100
(none)
The user ID and password do not need to be entered.
For two items marked with (*), settings made at the previous
login will be displayed as defaults.
The splash window is displayed.
Figure E-1-4
FieldMate Startup Sequence
Exit Sequence
E010202E.ai
Execute Menu File -> Exit or press
Windows Close button
“Do you really want to exit?”
Yes
Return
No
Exit FieldMate
Figure E-1-5
FieldMate Exit Sequence
