E-25
IM 01R01A01-01E 9th Edition : May 31, 2013-00
E030205E.ai
Figure E-3-7
Table E-3-1
Item Object Description Default
Change to “O/S
mode, while
download
FOUNDATION
fieldbus
Block Mode of Function Block changes to O/S while
downloading to FOUNDATION fieldbus device
automatically.
This is not applicable to ISA100, HART device DTM.
ON
ISA100
Block Mode of Function Block changes to O/S while
downloading to ISA100 device automatically.
This is not applicable to FOUNDATION fieldbus,
HART device DTM.
OFF
Update cycle
Dynamic variable
Specify update cycle of Dynamic variable in the DTM.
5 to 120 sec selectable.
30 sec
Static variable
Specify update cycle of Static variable in the DTM. 60
to 120 sec selectable.
60 sec
Specify update cycle of Image in the DTM. I.e.
Bitmap. 60 to 120 sec selectable.
60 sec
