App.-37
IM 01R01A01-01E 9th Edition : May 31, 2013-00
 Environment Settings
 Calling
Software Download for FOUNDATION fieldbus → click Environment Settings
App.E02E.ai
See contents to
select folders.
Figure App.-E-2 Environment Settings window
Software files folder: Default is Install drive: FM\DD
This is to specify the location of software files for download.
Result files folder: Default is Install drive: FM\Log\SDLResult
This is to specify the location of information log on downloading.
Set to default button: This is to return the setting to default.
Contents specified in the Environment Settings window remains until next setting change
will be specified.
 Software Download Operation Procedure
App.E03E.ai
In Fieldbus Device Tool window, click Update Device List button
and select the device. Click Software Download button.
In Download Setting window, click the row to select the device.
Click the check box.
Click Import ffd file button and select the Software Download file
(file extension is ffd). More than one Software Download files
can be imported.
Start Software Download for FOUNDATION fieldbus
Click Download button and download will be completed
In case that more than one file is imported, select the Software
Download file in the drop down menu of the cell named
Software file name..
Figure App.-E-3 Software Download Operation Procedure
