 Offline Operations
Even when FieldMate is not connected to field devices, it can set their parameters by using the
offline function of the database device and then download the parameters to the field devices.
The parameter values can be saved as a snapshot for later reference.
App.B01E.ai
Figure App.-B-1 Offline operation image
App.B02E.ai
Offline registration at Device Navigator
Start DTM
Display Offline parameters
Set the value to parameters
Save the parameters to DB
Exit DTM
Offline Operation Download Operation
Exit DTM
Connect the device to FieldMate
Start DTM
Display Offline parameters
Load the parameters from DB
Download to the device
Figure App.-B-2 Operation Flow of Device Setup
