E-53
IM 01R01A01-01E 9th Edition : May 31, 2013-00
 Startup
There are two startup procedures.
 Start DD Menu from Parameter Manager.
(Note): When you perform this procedure, Parameter Manager is minimized and becomes unavailable.
 Select the device of FOUNDATION fieldbus in Segment Viewer and start DD Menu.
 Window
E030401E.ai
Indicates a device tag.
This area displays the menu hierarchy
defined for device DD, which can be
navigated in the same way as Windows
Explorer to move through the menu
hierarchy.
This area displays elements defined in a selected hierarchy.
The following elements appear here.
(1) Parameters: Parameter names and values are indicated.
Writable parameters can be modified.
(2) Menus: Selecting a parameter allows you to move to a lower-level menu.
(3) Methods: Setting/adjustment processing can be performed using wizards.
This area displays operations made
using this tool. None of the items
displayed can be modified.
Figure E-3-29 DD Menu
