F-4 Device Navigator
Device Navigator registers the devices in the database.
It displays the device list registered in the database.
It also allows you to search the device or events in the database.
Device Maintenance Information are stored.
 Window
F040001E.ai
Displays search screen.
Displays all devices
registered in the database.
Column titles
Device Flag, Memo Flag, Device Tag, Device ID, Device Tag Comment,
Communication Type, Vendor, Model, Device Revision
Clicking each title allows items of the relevant
column to be sorted.
Also, using drag and drop of the title allows
position of columns to be rearranged.
Displays devices in Favorites.
Displays devices in Search
Results.
Displays devices of each
communication type.
Displays devices belonging to
each FDT project.
Figure F-4-1 Device Navigator (Normal Display)
