E-38

IM 01R01A01-01E

9th Edition : May 31, 2013-00

Setting Device Station Address for PROFIBUS Devices

TIP

If device is equipped with hardware switch, it needs to be disabled to perform the following operation.

1. Start the PROFIBUS device DTM to change the address.
2. Select FDT Topology from the View menu, and then select the device DTM in the FDT

Topology area and disconnect it.

E030209E.ai

Figure E-3-12

3. Select PROFIdtm DPV1 in the FDT Topology area, and then right-click Additional Functions

Set Device Station Address to display the Settings window, and change the address.

E030210E.ai

Figure E-3-13

TIP

Error message “Failed to set new address” may show up, depending on the connected devices. However

operation can continue.
