4. Operation Procedure
The parameters are converted in two steps as described below.
 Step 1
Upload the parameters of the original device to FieldMate and save them in a file.
App.C01E.ai
Upload Save
Original device FieldMate
Figure App.-C-1
 Step 2
Retrieve the parameters from the file and download them to the replacing device.
App.C02E.ai
Retrieve Download
FieldMate Replacing device
Figure App.-C-2
• At the end of Step 1, the parameters are automatically saved in a file (cannot be canceled).
• Steps 1 and 2 can be consecutively performed. Or, after Step 1 is finished, Step 2 can be
done later.
(Note) This tool works only for the combinations of devices listed in Table D-1.
