13. Frequency
Analysis Function for SCON-CA
Controller
Anti-V
ibration Control
235
Setting for print list range
Set the range of data rows you want to print by entering values in the “Print start time [sec]” and “Print end
time [sec]” input fields.
Only the measurement data rows included in the range set here will be printed.
The setting unit of fields in the “Setting for print list range” area is [sec].
[2] Print setting for analysis data
Fig. 13.37 Print Setting for Analysis Data
In this area, print setting for analysis data is performed.
Since the function of each setting item is the same as in [1], “Print setting for measurement data,” only
the printing format of analysis data is shown in the figure below.
• Print list:
Analysis data included in the range specified in the “Setting for print list range” area is printed in the
format specified below.
Fig. 11.38 Printing Format of Analysis Data List
Print type selection
Setting for print list range
