6. Initial Setting and Position Data Editing for SEP
Controllers
92
[5] Reading a File
To read position data from a file, click File and then select Open to open the “Open” window. Alternatively,
you can click File, point to Send to Controller and then select Position to open the “Open” window.
Fig. 6.30 “Open” Window
Select (click) “File name” you want to open, and click Open on the “Open” window, then the position data edit
window is displayed.
Select folder in which
position data is saved.
Saved file name
Select controller.
