11. Smart T
uning Function (V
ersion V8.03.00.00 or Later)
145
Adjustment gain
Since it is not applicable for PCON-CA and ERC3 gain tuning, adjustment gain display is shown with
blank.
Fig. 11.53 Adjustment gain (Not stored)
Sys identification
Since PCON-CA and ERC3 are not applicable for system identification, a blank is displayed here.
Fig. 11.54 Sys identification (Not stored)
Load
In “Carrier load select” window, the carrier load which was indicated is displayed.
Tuning
Since PCON-CA and ERC3 are not applicable for gain tuning, a blank is displayed here.
Comment
The comment, if any left in “Adjustment record data save” when the adjustment record was saved, is
displayed.
