12. Off Board T
uning Function on SCON-CA
Controller
177
12.5.3 Explanations for each Item in Carrier load Select Window
Set the carrier load in this window.
There are 2 ways for the selection of the carrier load, one is to indicate the carrier load and the other is to figure
out from the system identification, and selection can be made from these 2 ways.
(Note) The system identification is available to select only in the online work. In the offline work, the window
switches to the one as shown in Fig. 12.19.
Fig. 12.18 Carrier load Select Window (in online work)
[2] Carrier Load
Indication
[3] System Identification
Setting
[1] Carrier Load Indication
Method Select
[4] System Identification
Result
