12. Off Board T
uning Function on SCON-CA
Controller
208
Pattern select
Select the pattern to be displayed in the takt time calculation result graph with this combo box.
The pattern numbers that the takt time calculation was held with are available to choose.
Takt time (s)
The takt time for the pattern selected in the Pattern select is shown.
Cycle time (s)
The cycle time for the pattern selected in the Pattern select is shown.
Cycle time is the sum of takt time and pause time.
Load factor (%)
The load factor for the pattern selected in the Pattern select is shown.
Accum. cycle time (s)
The accumulative cycle time for those from Pattern 1 to the pattern selected in the Pattern select is
shown.
Accum. load factor (%)
The accumulative load factor for those from Pattern 1 to the pattern selected in the Pattern select is
shown.
Total cycle time (s)
In here, shows the total cycle time of all the patterns included in the takt time calculation.
Total factor load (%)
The total load factor for all the patterns the takt time calculation is conducted on is shown.
