8. Monitoring
98
8. Monitoring
Various statuses, controller error lists, and velocity/current waveforms (other than RCP, RCS and E-CON
models), can be monitored.
8.1 Status Monitor Window
To monitor various statuses, click Monitor and then select Status in the main menu, or click in the toolbar.
In the “Select axis number” window, select the axis number corresponding to the axis whose statuses you want
to monitor. (Refer to 4, “Selecting an Axis.”) (Fig.8.1 shows an example of the display when a PCON-C
controller is connected. Fig. 8.6 shows an example of the display when a RCP2 controller is connected. The
displayed information will vary depending on the controller type.)
