8. Monitoring
101
DO output test button
Clicking the DO output button opens the I/O Test window.
Here, you can click a desired port and add a check mark to forcibly turn ON the applicable signal.
Fig. 8.3 I/O Test Window
Fig. 8.4 Emergency Stop Indication
Fig. 8.5 Motor Voltage Low Indication
