13. Frequency
Analysis Function for SCON-CA
Controller
Anti-V
ibration Control
228
13.2.3 Analysis Result Display Window
Setting items common to all axes on the frequency analysis for vibration control window
Clicking the Execute FFT button performs FFT analysis and the display switches to this window.
Fig. 13.27 FFT Analysis Result Win
[1] FFT analysis setting data
[3] Maximum value of FFT [5] Axis number selection [7] Forward to Controller button
[2] Peak frequency setting [4] Frequency resolution [6] Parameter set number selection
