12. Off Board T
uning Function on SCON-CA
Controller
173
Adjustment Record Data Select
This is used when switch over the adjustment record data. Number of selectable adjustment record data
is shown on the right side.
It is able to narrow down the search of the adjustment record data by select actuator setting. The item
with blank in the select actuator setting gets excluded from the search conditions.
Example) If set as: Model Code = ISB-SXM-60, Lead = 4mm
Ÿ
The search result is narrowed down from the adjustment record data to those for
ISB-SXM-60 with 4mm lead.
Example) If set as: Model Code = ISB-SXM-60, Lead = Blank
Ÿ
The search result is narrowed down from the adjustment record data to those for
ISB-SXM-60 no matter the lead length.
Click on << or >> button and the data on the very end can be selected from the selectable
adjustment record data.
Click < or > button and the cursor moves from 1 record to the next in the selected
adjustment record data.
Putting a number between < and > buttons will select the indicated adjustment record data
directly.
