11.4.2 Explanation of Each Window for Test Run Operation
(1) Select actuator Window
Select the model in this window. Select the model in [2] Select actuator model, and click Next.
Fig. 11.46 Select actuator Window
[1] Displayed Window/Model Information Display Area
Fig. 11.47 Displayed Window/Model Information Display Area
Displayed Window Information
The name of the window currently displayed is shown.
Model Information
The information of actuator selected in “Select actuator” window is shown.
[1] Displayed Window/Model Information Display Area
[2] Select actuator model
[3] Adjustment record data Display Area [4] Common Buttons Area
[5] Database File Version Display Area
Displayed Window Information Model Information
