Page 73
Group and Location
E-Mon Energy User Manual
7-16
E-MON
Figure 7.13 - Group Tab displays group information
3
Type in or change the fields you want to modify.
4
At this point, you can click on the “√ ” button to accept/save the changes to fields.
How do I Select a Location and Scan for Meters?
Select Location
To select location:
1
From E-Mon Energy™ Explorer Window, click and select Hardware\Set Location from
the drop-down menu. The Select Location Dialog opens.
Figure 7.14 - Select Location Dialog
2
From the Group drop-down list, select a Group.
3
From the Location drop-down list, select a Location you want to scan and with which you
want to communicate.
4
Click on S
ET
button. The Access window opens.
Note: The Group and Location displays in the window’s status bar area.
Set button
