How do I Set up a New Location?
Setting up a New Location
To set up a new location:
1
Select Database\Location from the drop-down menu or click on the Location tab in the
Database
window.
Figure 7.9 - Database\Location drop-down menu
2
From the Device Explorer window, highlight and select the Group Number to add location.
3
Click on the Panel Action “
+
”
button to add a new location.
Figure 7.10 - Location Tab
4
In the Number field, type in a Location Number. Location 0 is reserved for the virtual
recorders and meters location.
Note: Must be a unique number between 0 and 32767. This field is required.
5
In the Name field, type a Location Name. This field is not required; however, we highly
recommend you provide a meaningful name up to 12 characters in length.
