Demand Profile Graph
E-Mon Energy User Manual
16-5
E-MON
How Do I Load a Profile and Generate a Demand Profile
Graph?
To Load a Profile
To load a profile:
1
From the E-Mon Energy™ explorer window, click and select Graph\Load Profile from
the drop-down menu. The following illustration shows the Load Profile Graph displays.
Figure 16.8 - Load Demand Profile
2
In the From (date) field, click on the drop-down arrow, then select a day, month, and year
to start plotting the meters.
Figure 16.9 - Time Period Calendar
3
In the To (date) field, click on the drop-down arrow, then select the day, month, and year to
stop
plotting the meters.
4
In the From (time) field, select the time (hrs: min: sec AM/PM) to Start at:
