E-Mon Energy Software - Manual (Page 64)

Group and Location
E-Mon Energy User Manual 7-7 E-MON
Selecting the AMR Schedule Call-Out (If using with Group Option)
To select an AMR Schedule Call-Out:
10 In the AMR Schedule (Call-out) group fields, select Schedule Name, Task Name from
each drop-down lists for only Schedule 1.
11 Check the “Enable AMR” box.
12 Click on the “√ ” button to accept/save the group record.
Can I Customize the Group AMR Schedule?
Yes, you can customize the default time for AMR call-in intervals. When “Use Group AMR” is checked, E-Mon
Energy™ will automatically assign a call-in time for each of the locations in the group. The initial schedule time will
be assigned to the first location, and subsequent location times will be offset by E-Mon Energy using the “AMR Call
Interval.” If you wish to customize these default times, see the procedure below.
Customizing the Group AMR Schedule
To customize the AMR Schedule Call-Out:
1 To further customize the AMR Schedule group, click on the C
USTOMIZE
button. A
Customize Group AMR dialog box should open.
Figure 7.6 - Customize Group AMR Schedule (Customize Schedule Tab)
2 From the Customize Schedule tab, under AMR Call Interval, select either “Use system
default” or “Select the Interval (hour:minute).”
3 If setting the interval, enter or click on the S up and T down arrows for minutes or hours.
Note: Default intervals are based on a single modem. If your computer has multiple modems
for auto answer, you may decrease the interval proportionally. Under the AMR Time Period
for this Group, to change hrs: min: sec: AM/PM for Ends at:
4
Click and type inside the text box to change each time increment or click on the Sup T
down arrows to adjust the time frame for each increment.
Note: The Start Time cannot exceed the End Time.
5 To view the Location details, click on the Location Tab.
