Group and Location
E-Mon Energy User Manual 7-15 E-MON
Selecting the AMR Schedule Call–In (If you are not using the Group
Option)
Note: If you plan to use the “Use Group AMR” option, check the “Use Group AMR” box and
proceed to How to Set a Location and Scan for Meters.
To select an AMR Schedule Call-In Schedule:
1 From the AMR Schedule (Call-In) group fields, select Schedule Name, Task, Server, and
Event Server
from drop-downs for only Schedule 1.
Note: If you create and save a new AMR schedule, Task, and Server, it should appear in the
drop-down list. Refer to AMR tab for details.
2 Check the “Enable AMR” box.
Selecting the AMR Schedule Call–Out (If you are not using the Group
Option)
Note: If you plan to use the “Use Group AMR” option, check the “Use Group AMR” box
and proceed to How to Set a Location and Scan for Meters
To select an AMR Schedule Call-In Schedule:
1 In the AMR Schedule (Call-out) group fields, select Schedule Name, Task Name from
drop-down for only Schedule 1.
2 Check the “Enable AMR” box.
3 Click on “√ ” button to accept/save the location record.
How do I Modify a Group or Location?
Modifying a Group or Location
To modify a Group or Location:
1 From the Device Explorer window, highlight and select either the Group Number or
Location Number.
Group
Location
Figure 7.12 - Selecting Group Number or Location Number
2 With Group or Location Number selected and highlighted, click on the Database drop-down
menu and select either group or location. In the following illustration, we selected Group
from the drop-down menu.
