E-Mon Energy User Manual 9-6 E-MON
9 Once E-Mon Energy™ scans and moves past the last installed device ID, wait a few
seconds and click C
ANCEL
. At this point, it will allow you to update the database.
10 Click on the
U PDATE D ATABASE
button and a dialog box displays with 4 list boxes: New
Device
, Add to DB, Bad Device, and Delete from DB. Note: The “New Device” list box
displays all new devices detected during the scan. The Bad devices will display under the
“Bad Device” list box. The database list boxes allow you to add a new device or remove a
bad device from that location.
Figure 9.6 - Update Database
11 In the New Device list box, click on a device. (e.g., 1A1).
12 Click on the > right arrow button to move the new device into the Add to DB list box. To
add all devices, click the >> right double arrow button and all devices will move to the Add
to DB
list box.
Figure 9.7 - Adding New Devices to Database
13 Click on the U
PDATE D BASE
button to add the devices to the database. The Access window
now displays meters as OK rather than NEW.
Figure 9.8 - Database update complete message dialog
