98 - 8645
ConfiGuraTion anD funCTion of The moDules
English
2 * 5/2-way valves (Type 6525) or 3/2-way valves (Type 6524)
1
2
4
5 6
Legend
1
2
3
4
5
6
FE contact
Label panels
LEDs for switching status
V1 – Valve function 1
V2 – Valve function 2
DIN rail mounting
Emergency manual control valve 1
Emergency manual control valve 2
Illustration: Overview PM PO2
2 * 5/2-way valve pulse-type or 5/3-way valve, pilot-controlled
(Type 0460)
1
2
4
5
6 8
7
Legend
1
2
3
4
5
6
7
8
FE contact
Label panels
LEDs for switching status
V1.1 – Valve function 1,1
V1.2 – Valve function 1,2
V2.1 – Valve function 2,1
V2.2 – Valve function 2,1
DIN rail mounting
Emergency manual control valve 1.1
Emergency manual control valve 1.2
Emergency manual control valve 2.1
Emergency manual control valve 2.2
Illustration: Overview PM PO4 (version Type 0460)
