ConfiGuraTion anD funCTion of The moDules
English
8645 - 97
dimensions
6,75
79,5
35,5
6,2 17,5
37 1)
A
0
9,5
124
131,54
138,2
8,5 21,5
50,7
Ш3,2
Ш3,2
3,5
12,5
37 1)
98,35
17,5
11,4
23
130,5
Illustration: Dimensions [mm] - pneumatic module
Overview of Pneumatic Modules
2 * 2x 3/2-way valves (Type 6524)
1
2
4
6
5 7
8
Legend
1
2
3
4
5
6
7
8
FE contact
Label panels
LEDs for switching status
V1 – Valve function 1
V2 – Valve function 2
V3 – Valve function 3
V4 – Valve function 4
DIN rail mounting
Emergency manual control valve 1
Emergency manual control valve 2
Emergency manual control valve 3
Emergency manual control valve 4
Illustration: Overview PM PO4
