ATmega163(L)
9
The General Purpose Register File
Figure 7 shows the structure of the 32 general purpose working registers in the CPU.
Figure 7. AVR CPU General Purpose Working Registers
All the register operating instructions in the instruction set have direct and single cycle access to all registers. The only
exception is the five constant arithmetic and logic instructions SBCI, SUBI, CPI, ANDI, and ORI between a constant and a
register, and the LDI instruction for load immediate constant data. These instructions apply to the second half of the regis-
ters in the register file - R16..R31. The general SBC, SUB, CP, AND, and OR and all other operations between two
registers or on a single register apply to the entire register file.
As shown in Figure 7, each register is also assigned a data memory address, mapping them directly into the first 32 loca-
tions of the user Data Space. Although not being physically implemented as SRAM locations, this memory organization
provides great flexibility in access of the registers, as the X, Y, and Z registers can be set to index any register in the file.
The X-register, Y-register, And Z-register
The registers R26..R31 have some added functions to their general purpose usage. These registers are address pointers
for indirect addressing of the Data Space. The three indirect address registers X, Y, and Z are defined as:
Figure 8. The X, Y, and Z Registers
7 0 Addr.
R0 $00
R1 $01
R2 $02
…
R13 $0D
General R14 $0E
Purpose R15 $0F
Working R16 $10
Registers R17 $11
…
R26 $1A X-register low byte
R27 $1B X-register high byte
R28 $1C Y-register low byte
R29 $1D Y-register high byte
R30 $1E Z-register low byte
R31 $1F Z-register high byte
15 XH XL 0
X - register 70 0 7 0
R27 ($1B) R26 ($1A)
15 YH YL 0
Y - register 70 0 7 0
R29 ($1D) R28 ($1C)
15 ZH ZL 0
Z - register 70 0 7 0
R30 ($1F) R31 ($1E)
