ATmega163(L)
143
Typical Characteristics - Preliminary Data
Analog comparator offset voltage is measured as absolute offset.
Figure 91. Analog Comparator Offset Voltage vs, Common Mode Voltage (V
CC
= 5V)
Figure 92. Analog Comparator Offset Voltage vs. Common Mode Voltage (V
CC
= 2.7V)
0
2
4
6
8
10
12
14
16
18
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
Common Mode Voltage (V)
Offset Voltage (mV)
T = 85 ˚ C
A
T = 25 ˚ C
A
0
2
4
6
8
10
0 0.5 1 1.5 2 2.5 3
Common Mode Voltage (V)
Offset Voltage (mV)
T = 85 ˚ C
A
T = 25 ˚ C
A
